  • ASME Sec V 2025

    ARTICLE MT-21
    INSERVICE PULSED EDDY CURRENT TECHNIQUE FOR
    CORROSION SCREENING
    MT-2110 SCOPE
    This Article specifies requirements for inservice pulsed
    eddy current (PEC) examination of components constructed
    from ferromagnetic materials for detection of
    corrosion or erosion or both.
    When specified by the invoking documents, the PEC examination
    described in this Article shall be used together
    with Article MT-1. Terms used in this Article are defined
    in Article MT-1, Mandatory Appendix I, MT-I-121.13.
    MT-2120 GENERAL
    (a) PEC examination, as described in this Article, is an
    examination of a low alloy carbon steel or cast iron component.
    PEC examination is usually performed through a
    cover. PEC examination is used to find areas with inservice
    anomalies (typically corrosion or erosion) either
    internally or externally.
    (b) The PEC examination system consists of a probe
    that contains a device for generating a (primary) magnetic
    field and a device for detecting the secondary field
    emanating from the component, resulting from eddy currents
    generated by the primary field. The device used for
    detection may be the same as the device used for generation
    of the primary magnetic field.
    (c) In common PEC examinations, the primary field is a
    direct current (DC) magnetic field that is switched to generate
    eddy currents. The time between switching, i.e., the
    time for which the DC magnetic field is on, is called the excitation
    pulse. Due to switching of the magnetic field, eddy
    currents are generated. After switching the magnetic
    field, the eddy currents will decay. The secondary magnetic
    field is recorded and displayed on a graph. In a successful
    examination, the characteristics of the shape of the
    decay curve are extracted. These characteristics correspond
    to the wall thickness of the component.
    (d) PEC examination is usually performed as a relative
    measurement, where the system is calibrated on a reference
    spot on the component.
    (e) PEC examination provides an estimation of volume
    of material under a footprint area. Basic measurement
    will yield a result roughly proportional to the average
    wall thickness in the area in which eddy currents are generated.
    The basics of PEC system operation are described
    in Nonmandatory Appendix A to this Article.
    MT-2121 WRITTEN PROCEDURE REQUIREMENTS
    MT-2121.1 Requirements. PEC examination shall be
    performed in accordance with a written procedure that
    shall, at a minimum, contain the requirements listed in
    Table MT-2121.1-1. The written procedure shall establish
    a single value, or range of values, for each requirement.
    MT-2121.2 Technical Feasibility Evaluation. Due to
    the properties of PEC examination, a technical feasibility
    evaluation shall be performed. This technical feasibility
    evaluation shall comprise the following, as a minimum:
    (a) an evaluation of the ability of PEC examination to
    penetrate the cover. This shall be performed with theoretical
    or practical methods.
    (b) an evaluation of the ability of PEC examination to
    detect anomalies sufficiently for the intended purpose
    of the examination. This may be performed theoretically
    or practically. The evaluation shall include a call level, a
    level over which indications are recommended for followup
    examination. The minimal detectable defect, as determined
    in the technical feasibility evaluation, shall be
    indicated.
    (c) a trial measurement on the component. The test
    measurements at the reference location (see MT-2151)
    may be the same as the trial measurement, provided the
    measurement results correspond to the results of (a)
    and (b). Correspondence shall be reported.
    MT-2121.3 Changes to Requirements. A change of a
    requirement in Table MT-2121.1-1 identified as an essential
    variable from the specified value, or range of values,
    shall require revision of the technical feasibility evaluation.
    A change of a requirement identified as a nonessential
    variable from the specified value, or range of values,
    does not require revision of the technical feasibility evaluation.
    All changes of essential or nonessential variables
    from the value, or range of values, specified by the written
    procedure shall require revision of, or an addendum to,
    the written procedure or scan plan, as applicable.
    MT-2122 SCAN PLAN
    A scan plan shall be developed. The scan plan shall address,
    as a minimum, the items listed under scan plan in
    Table MT-2121.1-1. Extent, location, and coverage of testing
    shall be graphically shown, e.g., on isometric drawings
    of piping or engineering drawings of the component, noting
    testing locations

  • SAE AS9102C


    SAE Executive Standards Committee Rules provide that: “This report is published by SAE to advance the state of technical and engineering sciences. The use of this report is
    entirely voluntary, and its applicability and suitability for any particular use, including any patent infringement arising therefrom, is the sole responsibility of the user.”
    SAE reviews each technical report at least every five years at which time it may be revised, reaffirmed, stabilized, or cancelled. SAE invites your written comments and
    suggestions.

    All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or transmitted, in any form or by any means, electronic, mechanical, photocopying,
    recording, or otherwise, without the prior written permission of SAE.
    TO PLACE A DOCUMENT ORDER: Tel: 877-606-7323 (inside USA and Canada)

    Technically equivalent writings published in all IAQG sectors
    (R) Aerospace Series – First Article Inspection Requirements
    RATIONALE
    This standard was revised to emphasize and enhance the First Article Inspection (FAI) planning, evaluation, and re-accomplishment activities; aligning requirements to the 9100 standard. Additional changes to the standard requirements, definitions, and associated notes were incorporated in response to stakeholder needs.
    FOREWORD
    To assure customer satisfaction, the aviation, space, and defense industry organizations must produce and continually improve safe, reliable products that meet or exceed customer and regulatory requirements. The globalization of the industry and the resulting diversity of regional/national requirements and expectations have complicated this objective. End-product organizations face the challenge of assuring the quality and integration of products purchased from suppliers throughout the world and at all levels of the supply chain. Industry suppliers face the challenge of delivering products to multiple customers having varying quality requirements and expectations.
    The aviation, space, and defense industry established the International Aerospace Quality Group (IAQG) for the purpose of achieving significant improvements in quality, delivery, safety, and reductions in cost throughout the value stream. This organization includes representation from companies in the Americas, Asia/Pacific, and Europe.
    This document standardizes FAI process requirements to the greatest extent possible. While primarily developed for the aviation, space, and defense industry, this standard can also be used in other industry sectors where a standardized FAI process is needed.
    SAE INTERNATIONAL AS9102™C Page 2 of 22
    TABLE OF CONTENTS

    • Provide confidence, through objective evidence, the product realization processes are capable of producing conforming product.
    • Demonstrate the manufacturers and processors of the product have an understanding of the associated requirements.
    • Provide assurance of product conformance at the start of production and after changes, as outlined in this standard.
      A FAI is intended to:
    • Mitigate risks associated with production startup and process changes.
    • Reduce future escapes.
    • Help ensure product safety.
    • Improve quality, delivery, and customer satisfaction.
    • Reduce costs and production delays associated with product nonconformances.
    • Identify product realization processes not capable of producing conforming characteristics, and initiate and/or validate associated corrective actions.
      1.3 Application
      This standard applies to organizations and their suppliers responsible for product realization processes that produce the design characteristics of the product. The organization shall flow down the requirements of this standard to suppliers who produce design characteristics.
      This standard also applies to suppliers performing special process(es). A Certificate of Conformance (CoC) provided by processors attests to satisfying the requirements. External suppliers providing special process(es) can satisfy this standard’s requirements by either:
    • Documenting the design characteristics and associated results on a First Article Inspection Report (FAIR).
    • Documenting the design characteristics and associated results on a detailed CoC.
      SAE INTERNATIONAL AS9102™C Page 4 of 22
      This standard applies to assemblies, sub-assemblies, and detail parts including castings, forgings, and modifications to standard catalogue or Commercial-Off-the-Shelf (COTS) items. Each of these items shall have a separate FAI.
      Unless contractually required, this standard does not apply to:
    • Development and prototype parts that are not considered as part of the first production run.
    • Procured standard catalogue item, COTS, or deliverable software. When these items are included in an assembly, they shall be documented in the index of part numbers in an assembly FAIR.
      1.4 Informative
      If there is a conflict between the requirements of this standard, and customer or applicable statutory/regulatory requirements, the latter shall take precedence.
      In this standard, the following verbal forms are used:
    • “Shall” indicates a requirement.
    • “Should” indicates a recommendation.
    • “May” indicates a permission.
    • “Can” indicates a possibility or a capability.
      Information marked as “NOTE” is for guidance in understanding or clarifying the associated requirement.
    1. APPLICABLE DOCUMENTS
      The following referenced documents support the application/use of this standard. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. When a conflict in requirements between this standard and the referenced documents below exist, the requirements of this document shall take precedence.
      9100 Quality Management Systems – Requirements for Aviation, Space, and Defense Organizations
      9103 Aerospace Series – Quality Management Systems – Variation Management of Key Characteristics
      As developed under the auspices of the IAQG and published by various standards bodies [e.g., ASD-STAN, SAE International, European Committee for Standardization (CEN), Japanese Standards Association (JSA)/Society of Japanese Aerospace Companies (SJAC), Brazilian Association for Technical Norms (ABNT)].
      ASME Y14.41 Digital Product Definition Data Practices
      ISO 9000 Quality management systems – Fundamentals and vocabulary
      ISO 16792 Digital Product Definition Data Practices
      SAE INTERNATIONAL AS9102™C Page 5 of 22
    2. TERMS AND DEFINITIONS
      Definitions for general terms can be found in ISO 9000 and the IAQG International Dictionary (located on the IAQG website). An acronym log for this standard is presented in Appendix A. For the purpose of this standard, the following definitions apply.
      3.1 ASSEMBLY
      A product that is produced by joining two or more detail parts, COTS, standard catalogue item, or sub-assemblies into one item.
      3.2 ATTRIBUTE DATA
      A result from a characteristic or property that is appraised only as to whether it does or does not conform to a given requirement (e.g., go/no-go, accept/reject, pass/fail).
      3.3 BALLOONED DESIGN CHARACTERISTIC
      Clear and uniquely identified design characteristic indicated on a ballooned document. The unique identifier may be circled or highlighted for easy visual identification.
      3.4 BALLOONED DOCUMENT
      An aid used in FAI to identify all the design characteristics, including all documents—e.g., drawings, purchase order, Digital Product Definition (DPD)—typically sequentially numbering the design characteristics and putting a circle around or highlighting the numbered design characteristics.
      3.5 BASELINE PART NUMBER
      This refers to a part number from the previous FAI or approved configuration, including revision level, to which a partial FAI is performed. An example of an approved configuration is a part produced and verified as conforming product prior to the requirements of this standard.
      3.6 COMMERCIAL-OFF-THE-SHELF (COTS) ITEM
      Commercially available item intended by design to be procured and utilized without modification (e.g., common electronic components). Any item or assembly meeting all of the following requirements:
      a. Defined by industry, manufacturer, military, or recognized specifications or standards.
      b. Without design modification, specifically for a customer.
      c. Customarily used by the public or industries.
      d. Offered for sale to the public, through catalogues, price list, brochures, stores, or websites.
      3.7 DELIVERABLE SOFTWARE
      Embedded or loadable airborne, spaceborne, or ground support software or firmware components which are part of an aircraft type design, weapon system, missile, or spacecraft.
      SAE INTERNATIONAL AS9102™C Page 6 of 22
      3.8 DESIGN CHARACTERISTIC
      Dimensional, visual, functional, mechanical, and material features or properties, which describe and constitute the design of the product. These characteristics can be measured, inspected, tested, or verified to determine conformance to the design requirements as specified on the parts list, purchasing document, drawing, or DPD, to which the product is to be produced.
    • Dimensional design characteristics include in-process locating features (e.g., additive manufacturing, target-machined or forged/cast dimensions on forgings and castings, weld/braze joint preparation necessary for acceptance of finished joint).
    • Material design characteristics include processing output variable (e.g., plating or coating thickness/runout, material hardness/conductivity). These provide assurance of intended characteristics that could not be otherwise defined.
      3.9 DESIGNED TOOLING
      Product specific tooling [e.g., check fixtures, Coordinate Measurement Machine (CMM) program] specifically made to validate the design characteristics of a product.
      3.10 DETAIL PART
      Article/part produced to engineering definition that does not include assembly processes (i.e., processes that join two or more parts together). Detail parts may include processing, finishes, and/or special process(es).
      3.11 DIGITAL PRODUCT DEFINITION (DPD)
      Digital data file(s) that disclose, directly or by reference, the physical or functional requirements, including data files that disclose the design or acceptance criteria of a product. Examples of DPD include the following:
    • Digital data file(s) and fully dimensioned two-dimensional (2D) drawing sheets.
    • Three-dimensional (3D) data model, and simplified or reduced content 2D drawing sheets.
    • 3D data model with design characteristics displayed as text.
    • Any other data files containing design characteristics that define a product in its entirety.
      3.12 FIRST ARTICLE INSPECTION (FAI)
      A planned, complete, independent, and documented inspection and verification process to ensure that prescribed production processes have produced an item conforming to engineering drawings, DPD, planning, purchase order, engineering specifications, and/or other applicable design documents.
      NOTE: The intent of independent as referenced above is to mitigate the effect of measurement error. This includes ensuring the person that verifies the characteristic for the first article not be the same person that generated the characteristic. Self-inspection (i.e., operator self-verification) is not considered independent. The equipment used to verify the characteristic should be different from the equipment used to produce the characteristic.
      3.13 FIRST ARTICLE INSPECTION REPORT (FAIR)
      Comprised of the forms identified in Appendix B, all ballooned design characteristics, and the supporting documentation determined by FAI planning for a part number (e.g., detail part, sub-assembly, or assembly).
      3.14 FIRST PRODUCTION RUN
      The initial group of one or more parts that are the result of a planned process designed to be used for production of these same parts.
      SAE INTERNATIONAL AS9102™C Page 7 of 22
      3.15 MODIFIED COMMERCIAL-OFF-THE-SHELF (COTS)/STANDARD CATALOGUE ITEM
      A COTS or Standard Catalogue item that has a change made to it from its original designed configuration.
      NOTE: Once modified, these items are categorized as detail parts for the purpose of assembly.
      3.16 MULTIPLE CHARACTERISTICS
      Identical characteristics that occur at more than one location (e.g., four places), but are identified by a single set of drawing or DPD requirements (e.g., rivet hole size, dovetail slots, corner radii, chemical milling pocket thickness).
      3.17 PRODUCT
      Any intended output resulting from the product realization process, which in the context of this standard includes finished detail parts, sub-assemblies, assemblies, forgings, and castings.
      3.18 QUALIFIED TOOLING
      Universal (not part specific) calibrated monitoring and measuring equipment (e.g., go/no go gauges, thread gauges, radius gauges) used to validate product design characteristics using attribute data.
      3.19 REFERENCE CHARACTERISTIC
      Characteristic (including reference and basic dimensions) that are used for “information only” or to show relationship; these are dimensions without tolerances and refer to other dimensions on the drawing or in the DPD.
      3.20 SPECIAL PROCESS
      Any process for production and service provision where the resulting output cannot be verified by subsequent monitoring or measurement and, as a consequence, deficiencies become apparent only after the product is in use or the service has been delivered.
      3.21 STANDARD CATALOGUE ITEM
      A part or material that conforms to an established industry or national authority published specification, having all characteristics identified by written description or an industry/national/military standard drawing.
      3.22 VARIABLE DATA
      Quantitative measurements taken on a continuous scale (e.g., the diameter of a cylinder, the gap between mating parts).
      SAE INTERNATIONAL AS9102™C Page 8 of 22

  • SAE AS9100D

    SAE INTERNATIONAL AS9100™D Page 17 of 54
    The organization shall consider:
    a. the capabilities of, and constraints on, existing internal resources;
    b. what needs to be obtained from external providers.
    7.1.2 People
    The organization shall determine and provide the persons necessary for the effective implementation of its quality
    management system and for the operation and control of its processes.
    7.1.3 Infrastructure
    The organization shall determine, provide, and maintain the infrastructure necessary for the operation of its processes and
    to achieve conformity of products and services.
    NOTE: Infrastructure can include:
    a. buildings and associated utilities;
    b. equipment, including hardware and software;
    c. transportation resources;
    d. information and communication technology.
    7.1.4 Environment for the Operation of Processes
    The organization shall determine, provide, and maintain the environment necessary for the operation of its processes and
    to achieve conformity of products and services.
    NOTE: A suitable environment can be a combination of human and physical factors, such as:
    a. social (e.g., non-discriminatory, calm, non-confrontational);
    b. psychological (e.g., stress-reducing, burnout prevention, emotionally protective);
    c. physical (e.g., temperature, heat, humidity, light, airflow, hygiene, noise).
    These factors can differ substantially depending on the products and services provided.
    7.1.5 Monitoring and Measuring Resources
    7.1.5.1 General
    The organization shall determine and provide the resources needed to ensure valid and reliable results when monitoring or
    measuring is used to verify the conformity of products and services to requirements.
    The organization shall ensure that the resources provided:
    a. are suitable for the specific type of monitoring and measurement activities being undertaken;
    b. are maintained to ensure their continuing fitness for their purpose.
    The organization shall retain appropriate documented information as evidence of fitness for purpose of the monitoring and
    measurement resources.
    SAE INTERNATIONAL AS9100™D Page 18 of 54 7.1.5.2 Measurement Traceability When measurement traceability is a requirement, or is considered by the organization to be an essential part of providing confidence in the validity of measurement results, measuring equipment shall be: a. calibrated or verified, or both, at specified intervals, or prior to use, against measurement standards traceable to international or national measurement standards; when no such standards exist, the basis used for calibration or verification shall be retained as documented information; b. identified in order to determine their status; c. safeguarded from adjustments, damage, or deterioration that would invalidate the calibration status and subsequent measurement results. The organization shall establish, implement, and maintain a process for the recall of monitoring and measuring equipment requiring calibration or verification. The organization shall maintain a register of the monitoring and measuring equipment. The register shall include the equipment type, unique identification, location, and the calibration or verification method, frequency, and acceptance criteria. NOTE: Monitoring and measuring equipment can include, but are not limited to: test hardware, test software, automated test equipment (ATE), and plotters used to produce verification data. It also includes personally owned and customer supplied equipment used to provide evidence of product and service conformity. Calibration or verification of monitoring and measuring equipment shall be carried out under suitable environmental conditions (see 7.1.4). The organization shall determine if the validity of previous measurement results has been adversely affected when measuring equipment is found to be unfit for its intended purpose, and shall take appropriate action as necessary. 7.1.6 Organizational Knowledge The organization shall determine the knowledge necessary for the operation of its processes and to achieve conformity of products and services. This knowledge shall be maintained and be made available to the extent necessary. When addressing changing needs and trends, the organization shall consider its current knowledge and determine how to acquire or access any necessary additional knowledge and required updates. NOTE 1: Organizational knowledge is knowledge specific to the organization; it is generally gained by experience. It is information that is used and shared to achieve the organization’s objectives. NOTE 2: Organizational knowledge can be based on: a. internal sources (e.g., intellectual property; knowledge gained from experience; lessons learned from failures and successful projects; capturing and sharing undocumented knowledge and experience; the results of improvements in processes, products and services); b. external sources (e.g., standards; academia; conferences; gathering knowledge from customers or external providers). Competence The organization shall: a. determine the necessary competence of person(s) doing work under its control that affects the performance and effectiveness of the quality management system; b. ensure that these persons are competent on the basis of appropriate education, training, or experience; c. where applicable, take actions to acquire the necessary competence, and evaluate the effectiveness of the actions taken; d. retain appropriate documented information as evidence of competence. NOTE: Consideration should be given for the periodic review of the necessary competence. NOTE: Applicable actions can include, for example, the provision of training to, the mentoring of, or the re-assignment of currently employed persons; or the hiring or contracting of competent persons. 7.3 Awareness The organization shall ensure that persons doing work under the organization’s control are aware of: a. the quality policy; b. relevant quality objectives; c. their contribution to the effectiveness of the quality management system, including the benefits of improved performance; d. the implications of not conforming with the quality management system requirements; e. relevant quality management system documented information and changes thereto; f. their contribution to product or service conformity; g. their contribution to product safety; h. the importance of ethical behavior. 7.4 Communication The organization shall determine the internal and external communications relevant to the quality management system, including: a. on what it will communicate; b. when to communicate; c. with whom to communicate; d. how to communicate; e. who communicates. NOTE: Communication should include internal and external feedback relevant to the quality management system. SAE INTERNATIONAL AS9100™D Page 20 of 54 7.5 Documented Information 7.5.1 General The organization’s quality management system shall include: a. documented information required by this International Standard; b. documented information determined by the organization as being necessary for the effectiveness of the quality management system. NOTE: The extent of documented information for a quality management system can differ from one organization to another due to: 􀃭 the size of organization and its type of activities, processes, products, and services; 􀃭 the complexity of processes and their interactions; 􀃭 the competence of persons. 7.5.2 Creating and Updating When creating and updating documented information, the organization shall ensure appropriate: a. identification and description (e.g., a title, date, author, or reference number); b. format (e.g., language, software version, graphics) and media (e.g., paper, electronic); c. review and approval for suitability and adequacy. NOTE: Approval implies authorized persons and approval methods are identified for the relevant types of documented information, as determined by the organization. 7.5.3 Control of Documented Information 7.5.3.1 Documented information required by the quality management system and by this International Standard shall be controlled to ensure: a. it is available and suitable for use, where and when it is needed; b. it is adequately protected (e.g., from loss of confidentiality, improper use, or loss of integrity). 7.5.3.2 For the control of documented information, the organization shall address the following activities, as applicable: a. distribution, access, retrieval, and use; b. storage and preservation, including preservation of legibility; c. control of changes (e.g., version control); d. retention and disposition; e. prevention of the unintended use of obsolete documented information by removal or by application of suitable identification or controls if kept for any purpose. -
    SAE INTERNATIONAL AS9100™D Page 21 of 54
    Documented information of external origin determined by the organization to be necessary for the planning and operation
    of the quality management system shall be identified as appropriate, and be controlled.
    Documented information retained as evidence of conformity shall be protected from unintended alterations.
    When documented information is managed electronically, data protection processes shall be defined (e.g.,
    protection from loss, unauthorized changes, unintended alteration, corruption, physical damage).
    NOTE: Access can imply a decision regarding the permission to view the documented information only, or the permission
    and authority to view and change the documented information.
    8. OPERATION
    8.1 Operational Planning and Control
    The organization shall plan, implement, and control the processes (see 4.4) needed to meet the requirements for the
    provision of products and services, and to implement the actions determined in clause 6, by:
    a. determining the requirements for the products and services;
    NOTE: Determination of requirements for the products and services should include consideration of:
    􀃭 personal and product safety;
    􀃭 producibility and inspectability;
    􀃭 reliability, availability, and maintainability;
    􀃭 suitability of parts and materials used in the product;
    􀃭 selection and development of embedded software;
    􀃭 product obsolescence;
    􀃭 prevention, detection, and removal of foreign objects;
    􀃭 handling, packaging, and preservation;
    􀃭 recycling or final disposal of the product at the end of its life.
    b. establishing criteria for:

  • SAE AMS2750H

    SAE AMS2750H  RATIONALE
    AMS2750H results from a Two-Year Review and update of this specification with changes to Definitions (see 2.4.21, 2.4.25, 2.4.36, 2.4.47, and 2.4.84); General Sensor Requirements (see Table 3); Sensor Calibration (see 3.1.4.6 and Table 5); SAT and TUS Sensor Reuse (see 3.1.7.4 and 3.1.7.5); Base Metal Load Sensors (see 3.1.10.3); General Instrumentation Requirements (see 3.2.1.4.1, 3.2.1.5, and Table 7); Control, Recording, and Over-Temperature Instruments (see 3.2.3.4, 3.2.3.5, 3.2.3.16, and 3.2.3.18); Instrumentation Calibration Results and Records (see 3.2.5.1); General Instrument Correction and Modification Offset Requirements (see 3.2.6.1.2 and 3.2.6.1.8); Thermal Processing Equipment (see 3.3.7); General SAT Requirements (see Table 11, Table 12, and 3.4.1.2.1); Performing an SAT (see 3.4.2.2); Alternate SAT Frequency (see 3.4.8.3); SAT Waiver (see 3.4.9.6.3); SAT Difference Pass/Fail Requirements (see 3.4.10.4); Comparison SAT (see 3.4.11.1.e); Parts furnace class, instrument type, and TUS internal (see Table 15); Raw material furnace class, instrument type, and TUS internal (see Table 16); Initial TUS Temperatures (see 3.5.2.4); TUS Requirements for Batch Furnaces, Salt Baths, Controlled Temperature Liquid Baths, and Fluidized Bed Furnaces (Excluding Controlled Temperature Quench Baths) (see Table 17); TUS Data Collection (see 3.5.10.1 and 3.5.10.2); Relocation of Hot or Cold Recording Sensors for Type A and C Instrumentation (see 3.5.15.2); Radiation Survey (see 3.5.17, 3.5.17.1, and 3.5.17.2); TUS Interval Deviations (see 3.5.18); Rounding (see 3.8); and Quality Assurance Provisions (see 4.2, 4.4, and Table 22). Deleted Zener Voltage Reference (was 3.5.87).

    1. SCOPE
      1.1 This specification covers pyrometric requirements for equipment used for the thermal processing of metallic materials. Specifically, it covers temperature sensors, instrumentation, thermal processing equipment, correction factors and instrument offsets, system accuracy tests, and temperature uniformity surveys. These are necessary to ensure that parts or raw materials are heat treated in accordance with the applicable specification(s).
      1.2 This specification may be used in other non-heat-treating applications when specified.
      1.3 This specification is not applicable to heating or to intermediate thermal processing unless otherwise specified.
      1.4 This specification applies to laboratory furnaces to the extent specified in 3.6.
    2. APPLICABLE DOCUMENTS
      The issue of the following documents in effect on the date of the purchase order forms a part of this specification to the extent specified herein. The supplier may work to a subsequent revision of a document unless a specific document issue is specified. When the referenced document has been cancelled and no superseding document has been specified, the last published issue of that document shall apply.
      SAE INTERNATIONAL AMS2750™H Page 2 of 57
      2.1 SAE Publications
      Available from SAE International, 400 Commonwealth Drive, Warrendale, PA 15096-0001, Tel: 877-606-7323 (inside USA and Canada) or +1 724-776-4970 (outside USA), www.sae.org.
      AS7766 Terms Used in Aerospace Metals Specifications
      2.2 ASTM Publications
      Available from ASTM International, 100 Barr Harbor Drive, P.O. Box C700, West Conshohocken, PA 19428-2959, Tel: 610-832-9585, www.astm.org.
      ASTM E29 Using Significant Digits in Test Data to Determine Conformance with Specifications
      ASTM E207 Standard Test Method for Thermal EMF Test of Single Thermoelement Materials by Comparison with a Reference Thermoelement of Similar EMF-Temperature Properties
      ASTM E220 Calibration of Thermocouples by Comparison Techniques
      ASTM E230 Temperature-Electromotive Force (EMF) Tables for Standardized Thermocouples
      ASTM E608 Mineral-Insulated, Metal-Sheathed Base Metal Thermocouples
      ASTM E1137 Industrial Platinum Resistance Thermometers
      ASTM E1751 Standard Guide for Temperature Electromotive Force (emf) Tables for Non-Letter Designated Thermocouple Combinations
      ASTM MNL7 Presentation of Data and Control Chart Analysis
      ASTM MNL12 Use of Thermocouples in Temperature Measurement
      2.3 IEC Publications
      Available from IEC Central Office, 3, rue de Varembe, P.O. Box 131, CH-1211 Geneva 20, Switzerland, Tel: +41 22 919 02 11, www.iec.ch.
      IEC 60751 Industrial Platinum Resistance Thermometers and Platinum Temperature Sensors
      ISO/IEC 17025 General Requirements for the Competence of Testing and Calibration Laboratories
      2.4 Definitions
      Terms used in AMS2750 are defined in AS7766 and as follows:
      2.4.1 ACCURACY
      The maximum deviation of the instrument or sensor being tested from the values of a traceable standard.
      2.4.2 ADJUSTMENT
      Any change to an instrument’s parameters.
      2.4.3 AUTOCLAVE
      An oven capable of operating at pressures higher than atmospheric pressure (nominally 760 mm Hg), commonly used in the processing of materials. It may be pressurized with steam, compressed air, or inert gas.
      SAE INTERNATIONAL AMS2750™H Page 3 of 57
      2.4.4 BASE METAL SENSOR
      Sensor whose thermoelements are composed primarily of base metals and their alloys. Examples of base metal sensors include Types E, J, K, N, M, and T.
      2.4.5 BATCH FURNACE
      A furnace where parts or raw material are stationary during the soak.
      NOTE: Some batch furnaces may oscillate material within a stationary work zone.
      2.4.6 BIAS or INPUT SHIFT
      The act of making an adjustment to an instrument to add, remove, or alter an offset.
      2.4.7 BIMONTHLY
      See FREQUENCY.
      2.4.8 BIWEEKLY
      See FREQUENCY.
      2.4.9 CALIBRATION
      An assessment of the accuracy of a sensor or an instrument to a traceable standard sensor and/or field test or standard instrument, based on one or more measurements, and potentially adjusting an instrument and/or compiling a deviation chart for a sensor or instrument in order to ensure compliance with requirements.
      2.4.10 CONTINUOUS FURNACE
      A furnace where parts or raw material are conveyed continuously or semi-continuously from the charge area to the discharge area. Examples include: bump furnace, shaker furnace, belt furnace, roller furnace, and rotary hearth furnace.
      2.4.11 CONTROL INSTRUMENT
      An instrument connected to a control sensor used to control the temperature of thermal processing equipment. The instrument may or may not also record temperature data.
      2.4.12 CONTROL SENSOR
      A sensor connected to a control instrument on thermal processing equipment, the temperature of which may or may not be recorded.
      2.4.13 CONTROL ZONE
      A portion of the working zone in thermal processing equipment having a separate sensor, instrument, and heating or cooling system to control its temperature. This portion of the thermal processing equipment is independently controlled.
      2.4.14 CONTROLLED TEMPERATURE LIQUID BATH
      A furnace containing a liquid that is heated to the desired heat-treat temperature. Parts and raw material are normally immersed in the liquid.
      2.4.15 CONTROLLER
      A digital or mechanical device that controls the temperature of thermal processing equipment (e.g., furnace control instruments, quench mechanical thermostat, freezer pressure controls, etc.).
      SAE INTERNATIONAL AMS2750™H Page 4 of 57
      2.4.16 CORRECTION FACTOR
      The number of degrees, determined from the most recent calibration, that must be added to, or subtracted from, the temperature reading of a sensor, or an instrument, or a combination thereof (system) to obtain true temperature. The correction factors of sensors and instruments are usually kept separately and added together algebraically when a combination is used. Correction factor is the algebraic opposite of deviation (error).
      2.4.17 DATA ACQUISITION SYSTEM
      An instrument system used to automatically collect and store process data as an electronic record; for example, a Programmable Logic Controller (PLC).
      2.4.18 DEVIATION/ERROR
      In the context of this specification, the difference between the uncorrected indicated temperature and the true temperature (Indicated Temperature – True Temperature = Deviation/Error).
  • SAE AMS2700G

    3.1.3 Method 2 – Passivation in Citric Acid
    3.1.3.1 Bath Composition
    Passivation shall be accomplished by immersion in an aqueous solution of 4 to 10 weight percent anhydrous citric acid (see 8.10). Additives such as wetting agents, inhibitors, and algicide or fungicide may be used as applicable. Other additives, such as ammonium hydroxide, may be used in order to stabilize or fix the pH of the bath as applicable.
    3.1.3.2 Operating Conditions
    Bath temperature shall be 70 to 160 °F (21 to 71 °C), with an immersion time of not less than 4 minutes for baths operating over 140 °F (60 °C), not less than 10 minutes for baths operating in the range of 120 to 140 °F (49 to 60 °C), not less than 20 minutes for baths operating in the range of 100 to 119 °F (38 to 48 °C), or not less than 30 minutes for baths operating below 100 °F (38 °C).
    3.1.4 Rinsing
    Immediately after removal from the passivating solution, the parts shall be thoroughly rinsed.
    3.1.4.1 The final rinse shall be carried out in clean water (see 8.12), followed by drying.
    SAE INTERNATIONAL AMS2700™G Page 6 of 13
    3.1.5 Post-Treatment
    When post-treatment is specified, directly after rinsing, parts made from ferritic, martensitic, or precipitation-hardening steels shall be immersed in a solution containing 4 to 6% by weight of sodium dichromate dihydrate (Na2Cr2O7·2H2O) at 140 to 160 °F (60 to 71 °C) for 1 hour, followed by rinsing and drying.
    3.1.5.1 When post-treatment is not specified, see 8.2 for guidance.
    3.2 Properties
    3.2.1 Corrosion Resistance
    Parts shall meet one of the following conditions or, when specified, a test in AMS-STD-753. When a test is not specified, any of these tests may be used. Parts containing 0.85% carbon or more (such as SAE 440C) shall be exempt from these tests.
    3.2.1.1 Humidity Test
    Parts shall be free from visible red rust after exposure to 95% minimum relative humidity at 100 to 115 °F (38 to 46 °C) for not less than 24 hours.
    3.2.1.2 Water Immersion Test
    Parts shall be free from visible red rust after alternately immersing in deionized or distilled water having an initial conductivity of 5 μS/cm or less for at least 1 hour and allowing to dry in room temperature air for at least 1 hour, until 12 cycles of immersion and drying have elapsed (see 8.13).
    3.2.1.3 Copper Sulfate Test
    A test solution containing 8 g of copper sulfate (CuSO4·5H2O) and 2 to 3 mL of sulfuric acid (H2SO4, sp. gr. 1.84) in 500 mL of high-purity water having a conductivity of 5 μS/cm or less (see 8.14) shall be applied to the part, or the part shall be immersed in the test solution. The part’s surface shall be kept wet for 6 to 6.5 minutes. Rinse and dry the surface without disturbing any deposits. Parts shall be free of any copper-colored deposits, which indicate the presence of unacceptable free iron. The effectiveness of copper sulfate solutions shall be validated by one of the following methods:

    • Periodic chemical analysis in accordance with 4.2.2.1.
    • Verification before use. A test specimen of any convenient size, made from any carbon or low-alloy steel (e.g., 1018 or 4130) and properly cleaned, shall exhibit a copper-colored deposit when subjected to the test above. Verification does not need to be performed more than once in any production day.
      3.2.1.3.1 The copper sulfate test is not recommended for use on martensitic 400 series alloys or for use on ferritic 400 series alloys containing less than 16% chromium because a copper deposit can result even though the passivation treatment was adequate.
      3.2.1.4 Salt Spray Test
      Parts shall withstand exposure to 2 hours minimum in a salt spray environment operated in accordance with ASTM B117. Parts shall be free from visible red rust following completion of the test.
      3.2.1.5 Ferroxyl Test
      Parts shall not show any traces of iron or iron oxide when the ferroxyl test is performed in accordance with ASTM A380. This is a hypersensitive test that may be used when traces of free iron or iron oxide might be objectionable.
      SAE INTERNATIONAL AMS2700™G Page 7 of 13
      3.2.2 Surface Appearance
      After completion of processing, there shall be no evidence of etching, pitting, smutting, frosting, dimensional changes, or other chemical attack on the parts when visually examined without aid of magnification. However, loss of temper color is acceptable.
      3.3 Written Procedure
      All processing and testing shall be done in accordance with a written procedure acceptable to the cognizant engineering organization (see 4.4.3).
    1. QUALITY ASSURANCE PROVISIONS
      4.1 Responsibility for Inspection
      The processor shall supply all test specimens for the processor’s tests and shall be responsible for the performance of all required tests. When parts are to be tested, such parts shall be supplied by the purchaser and, if acceptable after testing, may be included with the lot of processed parts. The cognizant engineering organization reserves the right to perform any confirmatory testing deemed necessary to ensure that processing conforms to specified requirements.
      4.2 Classification of Tests
      4.2.1 Acceptance Tests
      4.2.1.1 Classes 1, 2, and 4
      Corrosion resistance (see 3.2.1) and surface appearance (see 3.2.2) are acceptance tests and shall be performed on each lot.
      4.2.1.2 Class 3
      Surface appearance (see 3.2.2) is an acceptance test and shall be performed on each lot.
      4.2.2 Periodic Tests
      4.2.2.1 Compositions of passivating and post-treatment solutions are periodic tests and shall be performed at a frequency selected by the processor (see 8.7).
      4.2.2.2 Class 3 Parts
      Corrosion resistance (see 3.2.1) is a periodic test and shall be performed at a frequency selected by the processor.
      4.2.3 Preproduction Tests
      All technical requirements (see 3.2 and 3.3) of this specification are preproduction tests and shall be performed prior to production and when the cognizant engineering organization deems confirmatory testing is required.
      4.3 Sampling for Testing
      Sampling for testing shall not be less than the following: A lot shall be all parts of the same part number, processed in the same set of solutions within a 24-hour period, and presented for the processor’s inspection at the same time. Tested parts shall be selected randomly from all parts in each lot. Where parts are not available for testing, as in the case of large parts or parts that might be damaged by such testing, identically processed specimens fabricated from the same alloy as the parts represented may be used (see 8.8).
      4.3.1 Class 1 Parts
      The minimum number of parts or specimens selected for testing shall be as shown in Table 2.
      SAE INTERNATIONAL AMS2700™G Page 8 of 13
      Table 2 – Number of parts to be tested
      Number of Parts in Lot
      Surface
      Appearance
      Corrosion-Resistance Test
      1 to 6
      All
      2
      7 to 15
      7
      2
      16 to 40
      10
      3
      41 to 50
      15
      3
      51 to 110
      15
      5
      111 to 150
      25
      8
      151 to 500
      35
      8
      501 to 700
      50
      13
      701 to 1200
      75
      13
      Over 1200
      125
      13
      4.3.2 Class 2 parts or specimens shall be corrosion-resistance tested at a frequency of one part per lot and visually examined at the frequency given in Table 2.
      4.3.3 For Class 3 parts or specimens, sampling shall be established by the processor.
      4.3.4 Class 4 parts or specimens shall be selected for testing as shown in Table 3.
      Table 3 – Number of parts to be tested for Class 4
      Number of Parts in Lot(1)
      Surface Appearance
      Corrosion-Resistance Test(2)
      1 to 13
      All
      All
      14 to 1200
      13
      13
      1201 to 35000
      50
      13
      35001 to 500000
      80
      50
      (1) For Class 4, a lot shall consist of one of the following:
      a. Parts of similar alloy and manufacturing methods that are pretreated and passivated in one day’s production or within a time frame that will ensure consistent passivation results.
      b. The same product of one size from one heat in one shipment.
      c. When the quantity of passivated parts in one day’s production does not warrant daily testing, the lot size shall be as agreed upon by the cognizant engineering organization and the processor.
      (2) Identically processed specimens, made from the same alloys used to fabricate the parts, may be used for test purposes. The test specimens shall be randomly distributed throughout the lot during processing. When multiple tests are to be performed, separate specimens are required for each test.
      4.4 Approval
      4.4.1 The process and control procedures, a preproduction processed part, or both, whichever is specified, shall be approved by the cognizant engineering organization before production parts are supplied.
      4.4.2 If the processor makes a significant change to any material, process, or control factor that was used for process approval, all preproduction tests shall be performed and the results submitted to the cognizant engineering organization for process reapproval, unless the change is approved by the cognizant engineering organization. A significant change is one which, in the judgment of the cognizant engineering organization, could affect the properties or performance of the parts.
      SAE INTERNATIONAL AMS2700™G Page 9 of 13
      4.4.3 Control factors shall include, but are not limited to, the following:
      Method(s) for precleaning in preparation for passivating (see 3.1.1)
      Composition and composition limits of each processing solution
      Temperature and temperature limits of each processing solution
      Immersion time and time limits of the process for each processing solution
      Test(s) used for corrosion-resistance testing (see 3.2.1)
      Periodic test plan (see 4.2.2 and 8.7)
      4.5 Reports
      The processor shall furnish with each shipment a report stating that parts have been processed and tested in accordance with the specified requirements and that they conform to acceptance test requirements. Where post-treatment is used, the report shall so indicate that it was completed. The report shall state the method and, if applicable, type of passivation used, as well as the class and corrosion-resistance test(s) used. This report shall also include AMS2700G, the purchase order number, lot number(s), part number(s), and quantity of parts processed.
      4.6 Resampling and Retesting
      4.6.1 If any part subjected to surface appearance testing fails to meet requirements, that part shall be subject to rejection, and all parts in the lot shall be visually examined for conformance to surface appearance requirements or be subject to rejection.
      4.6.2 If any part subjected to corrosion-resistance testing fails to meet requirements, that part shall be subject to rejection. The balance of the lot may be reprocessed and retested using the sampling defined by Table 2 for the original number of parts in the lot, or all of the remaining parts in the lot shall be tested.
    2. PREPARATION FOR DELIVERY
      Packages of passivated parts shall be prepared for shipment in accordance with commercial practice and in compliance with applicable rules and regulations pertaining to the handling, packaging, and transportation of the processed parts.
    3. ACKNOWLEDGMENT
      A processor shall mention this specification number and its revision letter in all quotations and when acknowledging purchase orders.
    4. REJECTIONS
      Parts that are not processed in accordance with the requirements of this specification, or are processed with modifications not authorized by the cognizant engineering organization, will be subject to rejection.
    5. NOTES
      NOTICE
      This specification may reference the use of substances, products, or processes that are restricted or banned by local (regional) chemical substance regulations. Users of this specification should consider the implications of local legislation on the products, substances, and processes referred to within the document.
      8.1 Revision Indicator
      A change bar (I) located in the left margin is for the convenience of the user in locating areas where technical revisions, not editorial changes, have been made to the previous issue of this document. An (R) symbol to the left of the document title indicates a complete revision of the document, including technical revisions. Change bars and (R) are not used in original publications, nor in documents that contain editorial changes only.
      SAE INTERNATIONAL AMS2700™G Page 10 of 13
      8.2 When post-treatment is not specified, parts should be neutralized, preferably in a solution of 2 to 5% sodium hydroxide, followed by rinsing and drying.
      8.3 Dimensions and properties in inch/pound units and the Fahrenheit temperatures are primary; dimensions and properties in SI units and the Celsius temperatures are shown as the approximate equivalents of the primary units and are presented only for information.
      8.4 These processes have been used primarily to enhance the corrosion resistance of corrosion-resistant steel alloys, but the passivation process has also been successfully and historically applied to nickel-chromium high-temperature alloys and other nonferrous alloys for removal of free iron resulting from machining or other processing. Different types of smeared metal on the corrosion-resistant surfaces, or the presence of other surface treatments such as plating or braze filler metals, may dictate the use of either nitric acid or citric acid as applicable to the specific case.
      8.5 It is recommended that this process be used prior to heating corrosion-resistant steel parts to temperatures exceeding 1200 °F (649 °C) to prevent diffusion of contaminant free iron from the surface into the near-surface layer of parts.
      8.6 This document does not address methods for removal of scale or foreign materials from the surfaces of parts prior to passivation. Methods for accomplishing this may be found in such other documents as ISO 8074, ISO 8075, or ASTM A380.
      8.7 ARP4992 is recommended to satisfy the requirements for control of processing solutions.
      8.8 “Identically processed” as used in 4.3 refers to such operations as machining, grinding, heat treating, welding, media finishing, and similar processes.
      8.9 Passivating should be accomplished after completion of all manufacturing and inspection operations that could affect the passivity of the surface of the material, including but not limited to: forming, turning, milling, heat treatment, shot peening, media finishing, penetrant testing, or magnetic testing.
      8.9.1 Reworking operations that expose new surfaces or could affect the passivity of the surface should result in the subsequent re-passivation of the area (see 8.11.4).
      8.9.2 Where other surface-altering operations are performed, such as electroplating or nitriding, the purchaser should specify at which point the passivation operation is accomplished within the manufacturing sequence.
      8.9.3 Carburized and nitrided surfaces should not be passivated. Passivation solutions will severely corrode or pit nitrided surfaces. On carburized surfaces, the chromium combines with the carbon to form chromium carbides on the surface, which does not benefit from passivation. These surfaces should either be passivated prior to surface hardening or masked prior to passivation.
      8.10 Method 1 solutions may be made up and maintained with nitric acid at other than the specified 42 degree Baumé if the concentration is adjusted to compensate. Method 2 solutions may be made up and maintained with citric acid monohydrate if the formulation is adjusted accordingly to the equivalent amount of 4.4 to 10.9 weight percent. Method 2 solutions may be made up and maintained with citric acid stock solutions of a higher concentration when they are diluted appropriately.
      8.11 Guidelines for alternative passivation solutions that may be useful to the cognizant engineering organization are as follows:

    8.11 Guidelines for alternative passivation solutions that may be useful to the cognizant engineering organization are as follows:
    8.11.1 Bath Composition
    Passivation has been accomplished by immersion in a bath of an aqueous solution of 20 to 55% by volume of 42 degree Baumé (sp. gr. 1.4) nitric acid (HNO3) (see 8.10).
    8.11.1.1 It is recommended that the concentration of the nitric acid be above 40% for free machining steels.
    SAE INTERNATIONAL AMS2700™G Page 11 of 13
    8.11.1.2 Where the acid concentration is less than 35% by volume and for ferritic and martensitic steels, it is recommended that additional oxidizers be added to the bath in the form of 2 to 6% by weight of sodium dichromate dihydrate (Na2Cr2O7·2H2O).
    8.11.1.3 For the purpose of removing lead alloys from surfaces, molybdic acid (HMoO3) may be added to the bath at a concentration of up to 0.35 weight percent.
    8.11.2 Operating Conditions
    Bath temperature should be in the range of 70 to 155 °F (21 to 68 °C) with an immersion time of not less than 30 minutes for baths operating at temperatures below 100 °F (38 °C), not less than 20 minutes for baths operating at temperatures below 125 °F (52 °C), or not less than 10 minutes for baths operating at temperatures above 125 °F (52 °C).
    8.11.3 For certain high-carbon corrosion-resistant steels, such as SAE 440C, it may be desirable to passivate with the parts anodic for 2 to 3 minutes at 2 to 3 V to prevent etching.
    8.11.4 For local areas or where immersion is impractical, passivation has been accomplished by the use of thickened passivation solutions, such as pastes or gels, to maintain contact with stainless steel surfaces for the required time.
    8.12 It has been found that water containing up to 200 ppm total dissolved solids may be considered to be clean, but this limit is not a requirement. Rinsing may be accomplished with stagnant, countercurrent, and/or spray rinses.
    8.13 Distilled water may give more consistent results in the water immersion test compared to deionized water. Water used in the water immersion test will not maintain its initial conductivity during the test.
    8.14 High-purity water may be prepared by distillation, ion exchange, continuous electrodeionization, reverse osmosis, electrodialysis, or a combination thereof.
    8.15 It has been found that iron concentration in the passivating solution exceeding 2 weight percent may reduce the ability to remove iron contamination from parts.

  • ASME B31.3-2024

    A328.4 Preparation for Bonding
    Preparation shall be defined in the BPS and shall specify
    such requirements as
    (a) cutting
    (b) cleaning
    (c) preheat
    (d) end preparation
    (e) fit-up
    A328.5 Bonding Requirements
    A328.5.1 General
    (a) Production joints shall be made only in accordance
    with a written bonding procedure specification (BPS) that
    has been qualified in accordance with para. A328.2. Manufacturers
    of piping materials, bonding materials, and
    bonding equipment should be consulted in the preparation
    of the BPS.
    (b) Production joints shall be made only by qualified
    bonders or bonding operators who have appropriate
    training or experience in the use of the applicable BPS
    and have satisfactorily passed a performance qualification
    test that was performed in accordance with a qualified
    BPS.
    (c) Each qualified bonder and bonding operator shall
    be assigned an identification symbol. Unless otherwise
    specified in the engineering design, each pressurecontaining
    bond or adjacent area shall be stenciled or
    otherwise suitably marked with the identification
    symbol of the bonder or bonding operator. Identification
    stamping shall not be used and any marking paint or ink
    shall not be detrimental to the piping material. In lieu of
    marking the bond, appropriate records may be filed.
    (d) Qualification in one BPS does not qualify a bonder
    or bonding operator for any other bonding procedure.
    (e) Longitudinal joints are not covered in para. A328.
    A328.5.2 Hot Gas Welded Joints in Thermoplastic
    Piping5
    (a) Preparation. Surfaces to be hot gas welded together
    shall be cleaned of any foreign material. For butt welds, the
    joining edges should be beveled at 20 deg to 40 deg with 1
    mm (1∕32 in.) root face and root gap.
    (b) Procedure. Joints shall be made in accordance with
    the qualified BPS.
    (c) Branch Connections. A fabricated branch connection
    shall be made by inserting the branch pipe in the hole in
    the run pipe. Dimensions of the joint shall conform to
    Figure 328.4.3-1, illustration (c). The hole in the run
    pipe shall be beveled at 45 deg. Alternatively, a fabricated
    branch connection shall be made using a manufactured
    full reinforcement saddle with integral socket.
    A328.5.3 Solvent Cemented Joints in Thermoplastic ð24Þ
    Piping5
    (a) Preparation. Thermoplastic pipe and fitting
    surfaces shall be prepared in accordance with ASTM
    D2855 or ASME NM.1, para. 5-3.5 for PVC, ASTM F493
    or ASME NM.1, para. 5-3.5 for CPVC, or ASTM D2235
    for ABS. A dry fit test of each joint is required before
    solvent cementing. The pipe shall enter the fitting
    socket between one-third and two-thirds of the full
    socket depth when assembled by hand.
    (b) Procedure. Joints shall be made in accordance with
    the qualified BPS. ASTM D2855 or ASME NM.1, para. 5-3.5
    may be utilized as a suitable basis for development of such
    a procedure. Solvent cements for PVC, CPVC, and ABS shall
    conform to ASTM D2564, ASTM D2846, and ASTM D2235,
    respectively. Application of cement to both surfaces to be
    joined and assembly of these surfaces shall produce a
    continuous bond between them with visual evidence of
    cement at least flush with the outer end of the fitting
    bore around the entire joint perimeter. See Figure
    A328.5.3-1.
    (c) Branch Connections. A fabricated branch connection
    shall be made using a manufactured full reinforcement
    saddle with integral branch socket. The reinforcement
    saddle shall be solvent cemented to the run pipe over
    its entire contact surface.
    A328.5.4 Heat Fusion Joints in ThermoplasticPiping5 ð24Þ
    (a) Preparation. Surfaces to be heat fused together shall
    be cleaned of all foreign material.
    (b) Procedure. Joints shall be made in accordance with
    the qualified fusing procedure specification (FPS). Procedure
    1, Socket Fusion, Procedure 2, Butt Fusion, and
    Procedure 3, Saddle Fusion, in both ASTM F2620 and
    ASTM D2657, provide a suitable basis for development
    of such a procedure. Uniform heating of both surfaces
    to be joined and assembly of these surfaces shall
    produce a continuous homogeneous bond between
    them and shall produce a small fillet of fused material
    at the outer limits of the joint. See Figure A328.5.4-1
    Figure A328.5.3-1
    Thermoplastic Solvent Cemented Joint
    Socket Joint

    APPENDIX G
    SAFEGUARDING
    ð24Þ G300 SCOPE
    (a) Safeguarding is the provision of protective
    measures to minimize the risk of accidental damage to
    the piping or to minimize the harmful consequences of
    possible piping failure.
    (b) In most instances, the safeguarding inherent in the
    facility (the piping, the plant layout, and its operating practices)
    is sufficient without need for additional safeguarding.
    In some instances, however, additional
    engineering safeguards are required.
    (c) Appendix G outlines some considerations
    pertaining to the selection and utilization of safeguarding.
    Where safeguarding is required by the Code, it is necessary
    to consider only the safeguarding that will be suitable
    and effective for the purposes and functions stated in the
    Code or evident from the designer’s analysis of the application.
    G300.1 General Considerations
    In evaluating a piping installation design to determine
    what safeguarding may exist or is necessary, the following
    should be reviewed:
    (a) the hazardous properties of the fluid, considered
    under the most severe combination of temperature, pressure,
    and composition in the range of expected operating
    conditions.
    (b) the quantity of fluid that could be released by piping
    failure, considered in relation to the environment, recognizing
    the possible hazards ranging from large releases of
    otherwise innocuous fluids to small leakages of toxic
    fluids.
    (c) expected conditions in the environment, evaluated
    for their possible effect on the hazards caused by a
    possible piping failure. This includes consideration of
    ambient or surface temperature extremes, degree of ventilation,
    proximity of fired equipment, etc.
    (d) the probable extent of operating, maintenance, and
    other personnel exposure, as well as reasonably probable
    sources of damage to the piping from direct or indirect
    causes.
    (e) the probable need for grounding of static charges to
    prevent ignition of flammable vapors.
    (f) the safety inherent in the piping by virtue of materials
    of construction, methods of joining, and history of
    service reliability.
    G300.2 Safeguarding by Plant Layout and
    Operation
    Representative features of plant layout and operation
    that may be evaluated and selectively utilized as safeguarding
    include
    (a) plant layout features, such as open-air process
    equipment structures; spacing and isolation of hazardous
    areas; slope and drainage; buffer areas between plant
    operations and populated communities; or control over
    plant access
    (b) protective installations, such as fire protection
    systems; barricades or shields; ventilation to remove
    corrosive or flammable vapors; instruments for remote
    monitoring and control; containment and/or recovery
    facilities; or facilities (e.g., incinerators) for emergency
    disposal of hazardous materials
    (c) operating practices, such as restricted access to
    processing areas; work permit system for hazardous
    work; or special training for operating, maintenance,
    and emergency crews
    (d) means for safe discharge of fluids released during
    pressure relief device operation, blowdown, cleanout, etc.
    (e) procedures for startup, shutdown, and management
    of operating conditions, such as gradual pressurization
    or depressurization, and gradual warmup or
    cooldown, to minimize the possibility of piping failure,
    e.g., brittle fracture
    G300.3 Engineered Safeguards
    Engineered safeguards that may be evaluated and selectively
    applied to provide added safeguarding include
    (a) means to protect piping against possible failures,
    such as
    (1) thermal insulation, shields, or process controls to
    protect from excessively high or low temperature and
    thermal shock
    (2) armor, guards, barricades, or other protection
    from mechanical abuse
    (3) damping or stabilization of process or fluid flow
    dynamics to eliminate or to minimize or protect against
    destructive loads (e.g., severe vibration pulsations, cyclic
    operating conditions)
    (b) means to protect people and property against
    harmful consequences of possible piping failure, such
    as confining and safely disposing of escaped fluid by

  • ASME BPVC.VIII.1-2025Division

    ASME BPVC.VIII.1-2025

    SUBSECTION A
    GENERAL REQUIREMENTS
    PART UG
    GENERAL REQUIREMENTS FOR ALL METHODS OF
    CONSTRUCTION AND ALL MATERIALS
    UG-1 SCOPE
    The requirements of Part UG are applicable to all pressure
    vessels and vessel parts and shall be used in conjunction
    with the specific requirements in Subsections B, C,
    and D and the Mandatory Appendices that pertain to
    the method of fabrication and the material used.
    MATERIALS
    UG-4 GENERAL
    (a) Material subject to stress due to pressure shall conform
    to one of the specifications given in Section II, Part D,
    Subpart 1, Tables 1A, 1B, and 3, including all applicable
    notes in the tables, and shall be limited to those that are
    permitted in the applicable Part of Subsection C, except
    as otherwise permitted in UG-9; UG-10; UG-11; UG-15;
    Part UCS; Subsection D, Part UIG; and the Mandatory Appendices.
    Material may be identified as meeting more
    than one material specification and/or grade, provided
    the material meets all requirements of the identified material
    specification(s) and/or grade(s) [see UG-23(a)].
    (b) Material for nonpressure parts, such as skirts, supports,
    baffles, lugs, clips, and extended heat transfer surfaces,
    need not conform to the specifications for the
    material to which they are attached or to a material specification
    permitted in this Division, but if attached to the
    vessel by welding shall be of weldable quality [see
    UW-5(b)]. The allowable stress values for material not
    identified in accordance with UG-93 shall not exceed
    80% of the maximum allowable stress value permitted
    for similar material in Subsection C.
    (c) Material covered by specifications in Section II is
    not restricted as to the method of production unless so
    stated in the specification, and so long as the product
    complies with the requirements of the specification.
    (See UG-85.)
    (d) Materials other than those allowed by the rules of
    this Division shall not be used. Data for new materials
    shall be submitted to and approved by the ASME Boiler
    and Pressure Vessel Committee on Materials in accordance
    with Section II, Part D, Mandatory Appendix 5.
    (e) Materials outside the limits of size and/or thickness
    given in the title or scope clause of the specifications given
    in Section II, and permitted by the applicable Part of
    Subsection C, may be used if the material is in compliance
    with the other requirements of the specification,6 and no
    size or thickness limitation is given in the stress tables. In
    those specifications in which chemical composition or
    mechanical properties vary with size or thickness, materials
    outside the range shall be required to conform to
    the composition and mechanical properties shown for
    the nearest specified range.
    (f) It is recommended that the user or the user’s designated
    agent ensure that materials used for the construction
    of the vessels will be suitable for the intended
    service with respect to retention of satisfactory mechanical
    properties, and resistance to corrosion, erosion, oxidation,
    and other deterioration during their intended
    service life. See also informative and nonmandatory guidance
    regarding metallurgical phenomena in Section II,
    Part D, Nonmandatory Appendix A.
    (g) When specifications, grades, classes, and types are
    referenced, and the material specification in Section II,
    Part A or Part B is a dual‐unit specification (e.g.,
    SA-516/SA-516M), the design values and rules shall be
    applicable to either the U.S. Customary version of the material
    specification or the SI unit version of the material
    specification. For example, when SA-516M Grade 485 is
    used in construction, the design values listed for its
    equivalent, SA-516 Grade 70, in either the U.S. Customary
    or metric Section II, Part D (as appropriate) shall be used.
    (h) When the rules of this Division require the use of
    material physical properties, these properties shall be
    taken from the applicable tables in Section II, Part D,
    UG-1 – UG-4 ASME BPVC.VIII.1-2025
    8

    Subpart 2. If the applicable tables in Section II, Part D,
    Subpart 2 do not contain these properties for a permitted
    material or do not list them within the required temperature
    range, the Manufacturer may use other authoritative
    sources for the needed information. The Manufacturer’s
    Data Report shall note under “Remarks” the property values
    obtained and their source.
    NOTE: If material physical properties are not listed, the Manufacturer
    is encouraged to bring the information to the attention of the
    ASME Committee on Materials (BPV Section II) so that the data
    can be added in Section II, Part D, Subpart 2.
    UG-5 PLATE7
    Plate used in the construction of pressure parts of pressure
    vessels shall conform to one of the specifications in
    Section II for which allowable stress values are given in
    the tables referenced in UG-23, except as otherwise provided
    in UG-4, UG-10, UG-11, and UG-15.
    UG-6 FORGINGS
    (a) Specifications and maximum allowable stress values
    for acceptable forging materials are given in the
    tables referenced in UG-23. (See Part UF for forged
    vessels.)
    (b) Bar [as defined in UG-14(a)] that is forged independent
    of the material specification to which it is certified
    may be used only within the limitations of UG-14.
    (c) Forgings certified to SA-105, SA-181, SA-182,
    SA-350, SA-403, and SA-420 may be used as tubesheets
    and hollow cylindrical forgings for pressure vessel shells
    that otherwise meet all the rules of this Division, provided
    the following additional requirements are met:
    (1) Forgings certified to SA-105 or SA-181 shall be
    subject to one of the austenitizing heat treatments permitted
    by these specifications.
    (2) One tension test specimen shall be taken from
    each forging weighing more than 5,000 lb (2 250 kg).
    The largest obtainable tension test specimen as specified
    by the test methods referenced in the applicable specification
    shall be used. Except for upset-disk forgings, the longitudinal
    axis of the test specimen shall be taken parallel
    to the direction of major working of the forging. For
    upset-disk forgings, the longitudinal axis of the test specimen
    shall be taken in the tangential direction. When
    agreed to by the Manufacturer, and when not prohibited
    by the material specification, test specimens may be machined
    from specially forged test blocks meeting the provisions
    provided in SA-266 or other similar specifications
    for large forgings.
    (3) For quenched and tempered forgings weighing
    more than 10,000 lb (4 500 kg) at the time of heat treatment,
    two tension test specimens shall be taken from
    each forging. These shall be offset 180 deg from each
    other, except that if the length of the forging, excluding
    test prolongations, exceeds 12 ft (3.7 m), then one specimen
    shall be taken from each end of the forging.
    UG-7 CASTINGS
    Cast material may be used in the construction of pressure
    vessels and vessel parts. Specifications and maximum
    allowable stress values for acceptable casting
    materials are given in the tables referenced in UG-23.
    These allowable stress values shall be multiplied by the
    applicable casting quality factor given in UG-24 for all materials
    except cast iron.
    UG-8 PIPE AND TUBES
    (a) Pipe and tubes of seamless or welded8 construction
    conforming to one of the specifications given in Section II
    may be used for shells and other parts of pressure vessels.
    Allowable stress values for the materials used in pipe and
    tubes are given in the tables referenced in UG-23.
    (b) Integrally finned tubes may be made from tubes
    that conform in every respect with one of the specifications
    given in Section II. The requirements of (1), (2),
    (3), and (5) do not apply to tubes produced in accordance
    with a Section II integrally-finned material specification.
    These tubes may be used under the following conditions:
    (1) The tubes, after finning, shall have a temper or
    condition that conforms to one of those provided in the
    governing specifications, or, when specified, they may
    be furnished in the “as‐fabricated condition” where the
    finned portions of the tube are in the cold worked temper
    (as‐finned) resulting from the finning operation, and the
    unfinned portions in the temper of the tube prior to
    finning.
    (2) The maximum allowable stress value for the
    finned tube shall be that given in the tables referenced
    in UG-23 for the tube before finning except as permitted
    in (3) below.
    (3) The maximum allowable stress value for a temper
    or condition that has a higher stress value than that
    of the tube before finning may be used, provided that qualifying
    mechanical property tests demonstrate that such a
    temper or condition is obtained and conforms to one of
    those provided in the governing specifications in Section
    II, and provided that allowable stress values have been established
    in the tables referenced in UG-23 for the tube
    material used. The qualifying mechanical property tests
    shall be made on specimens of finned tube from which
    the fins have been removed by machining. The frequency
    of tests shall be as required in the unfinned tube
    specification.
    (4) The maximum allowable internal or external
    working pressure of the tube shall be based on the root
    diameter and the minimum wall of the finned section,
    or the outside diameter and wall of the unfinned section
    together with appropriate stress values, whichever results
    in the lower maximum allowable working pressure.
    Alternatively, the maximum allowable external pressure
    for tubes with integral fins may be established under
    the rules of Mandatory Appendix 23.
    ASME BPVC.VIII.1-2025 UG-4 – UG-8
    9with such other markings as will serve to identify the particular
    parts with accompanying material identification.
    The Manufacturer of the completed vessel shall be satisfied
    that the part is suitable for the design conditions specified
    for the completed vessel in accordance with the
    rules of this Division.
    (c) Cast, Forged, Rolled, or Die Formed Standard Pressure
    Parts That Comply With an ASME Product Standard,
    Either Welded or Nonwelded
    (1) These are pressure parts that comply with an
    ASME product standard accepted by reference in
    UG-44(a). The ASME product standard establishes the basis
    for the pressure–temperature rating and marking unless
    modified in UG-44(a).
    (2) Flanges and flanged fittings may be used at the
    pressure–temperature ratings specified in the appropriate
    standard listed in this Division.
    (3) Materials for standard pressure parts shall be as
    follows:
    (-a) as permitted by this Division or
    (-b) as specifically listed in the ASME product
    standard
    (4) When welding is performed it shall meet the
    following:
    (-a) the requirements of UW-26(a), UW-26(b),
    and UW-26(c) and UW-27 through UW-40, or;
    (-b) the welding requirements of ASME specification
    SA-234.
    (5) Standard pressure parts as identified in UG-11(c)
    do not require inspection, identification in accordance
    with UG-93.1 or UG-93.2, or Partial Data Reports, provided
    the requirements of UG-11(c) are met.
    (6) If postweld heat treatment is required by the
    rules of this Division, it may be performed either in the location
    of the parts manufacturer or in the location of the
    Manufacturer of the vessel to be marked with the Certification
    Mark.
    (7) If radiography or other volumetric examination is
    required by the rules of this Division, it may be performed
    at one of the following locations:
    (-a) the location of the Manufacturer of the completed
    vessel
    (-b) t h e l o c a t i o n of the pressure p a r t s
    manufacturer
    (8) Parts made to an ASME product standard shall be
    marked as required by the ASME product standard.
    (9) The Manufacturer of the completed vessels shall
    have the following responsibilities when using standard
    pressure parts that comply with an ASME product

  • ASME BPVC.IX-2025

    ASME BPVC.IX-2025 ARTICLE 5
    TESTS, INSPECTION, AND MARKING
    HG-500 PROOF TESTS TO ESTABLISH DESIGN
    PRESSURE
    HG-501 General
    (a) The design pressure for pressure parts of boilers for
    which the strength cannot be computed with a satisfactory
    assurance of accuracy shall be established in accordance
    with the requirements of this paragraph, using one of the
    test procedures applicable to the type of loading and to the
    material used in its construction.
    (b) The tests in these paragraphs may be used only for
    the purpose of establishing the design pressure of those
    elements or component parts for which the thickness
    cannot be determined by means of the design rules
    given in the Code. The design pressure of all other
    elements or component parts shall not be greater than
    that determined by means of the applicable design rules.
    HG-501.1 Types of Tests. Provision is made for two
    types of tests for determining the internal design
    pressure:
    (a) tests based on yielding of the part to be tested; these
    tests are limited to materials with a ratio of minimum
    specified yield to minimum specified ultimate strength
    of 0.625 or less. If a proof-tested part shows no evidence
    of permanent yielding per HG-502.1 and HG-502.2, it may
    be marked with the Certification Mark.
    (b) tests based on bursting of the part. The Certification
    Mark shall not be applied on the part proof tested under
    the burst-test provisions.
    HG-501.2 Retests. A retest shall be allowed on a
    duplicate pressure part if errors or irregularities are
    obvious in the test results.
    HG-501.3 Precautions. Safety of testing personnel
    should be given serious consideration when conducting
    proof tests, and particular care should be taken during
    the conducting of bursting tests per HG-502.3.
    HG-501.4 Pressure Application.
    (a) Previously Applied. The pressure parts for which the
    design pressure is to be established shall not previously
    have been subjected to a pressure greater than 11∕2 times
    the desired or anticipated design pressure.
    (b) Application. In the procedures given in HG-502.1 for
    the strain measurement test and HG-502.2 for the displacement
    measurement test, the hydrostatic pressure
    in the pressure part shall be increased gradually until
    approximately one-half the anticipated design pressure
    is reached. Thereafter, the test pressure shall be increased
    in steps of approximately one-tenth or less of the anticipated
    design pressure until the pressure required by the
    test procedure is reached. The pressure shall be held
    stationary at the end of each increment for a sufficient
    time to allow the observations required by the test procedure
    to be made and shall be released to zero to permit
    determination of any permanent strain or displacement
    after any pressure increment that indicates an increase in
    strain or displacement over the previous equal pressure
    increment.
    HG-501.5 Critical Areas. As a check that the
    measurements are being taken on the most critical
    areas, the Inspector may require a lime wash or other
    brittle coating to be applied on all areas of probable
    high stress concentrations in the test procedures given
    in HG-502.1 and HG-502.2. The surfaces shall be suitably
    clean before the coating is applied in order to obtain satisfactory
    adhesion. The technique shall be suited to the
    coating material.
    NOTE: Strains should be measured as they apply to membrane
    stresses. In regard to bending stresses it is recognized that high
    localized and secondary stresses may exist in pressure parts
    designed and fabricated in accordance with these rules.
    Insofar as practical, design rules for details have been
    written to hold such stresses at a safe level consistent with
    experience.
    HG-501.6 Yield Strength and Tensile Strength.
    For proof tests based on yielding, HG-502.1 and
    HG-502.2, the yield strength (or yield point for those materials
    that exhibit that type of yield behavior indicated by a
    “sharp-kneed” portion of the stress–strain diagram) of the
    material in the part tested, shall be determined in accordance
    with the method prescribed in the applicable material
    specification and as described in ASTM E8, Tension
    Testing of Metallic Materials. For proof tests based on
    bursting, HG-502.3, the tensile strength instead of the
    yield strength of the material in the part tested shall
    be similarly determined.
    ASME BPVC.IV-2025
    37

    electrode, stranded: a composite filler metal electrode
    consisting of stranded wires which may mechanically
    enclose materials to improve properties, stabilize the
    arc, or provide shielding.
    electrode, tungsten: a nonfiller metal electrode used in arc
    welding, arc cutting, and plasma spraying, made principally
    of tungsten.
    electrofusion (EF): fusing accomplished by heating polyethylene
    materials above their melting points using electric
    elements within a confined space, producing
    temperatures and pressures necessary to achieve coalescence
    of the molten polyethylene materials during the
    cooling phase. Some of the more common terms relating
    to EF are defined in ASTM F1290 and ASTM F412.
    electrofusion manufacturer: the manufacturer of electrofusion
    fittings.
    face feed: the application of filler metal to the face side of a
    joint.
    filler metal: the metal or alloy to be added in making a
    welded, brazed, or soldered joint.
    filler metal, brazing: the metal or alloy used as a filler metal
    in brazing, which has a liquidus above 840°F (450 °C) and
    below the solidus of the base metal.
    filler metal, powder: filler metal in particle form.
    filler metal, supplemental: in electroslag welding or in a
    welding process in which there is an arc between one
    or more consumable electrodes and the workpiece, a
    powder, solid, or composite material that is introduced
    into the weld other than the consumable electrode(s).
    fillet weld: a weld of approximately triangular cross
    section joining two surfaces approximately at right
    angles to each other in a lap joint, tee joint, or corner joint.
    flaw: an undesirable discontinuity. See also defect.
    flux (welding or brazing): a material used to dissolve,
    prevent, or facilitate the removal of oxides or other undesirable
    surface substances. It may act to stabilize the arc,
    shield the molten pool, and may or may not evolve
    shielding gas by decomposition.
    flux cover: metal bath dip brazing and dip soldering. A layer
    of molten flux over the molten filler metal bath.
    flux, active (SAW): a flux from which the amount of
    elements deposited in the weld metal is dependent
    upon the welding parameters, primarily arc voltage.
    flux, alloy (SAW): a flux which provides alloying elements
    in the weld metal deposit.
    flux, neutral (SAW): a flux which will not cause a significant
    change in the weld metal composition when there is a
    large change in the arc voltage.
    forehand welding: a welding technique in which the
    welding torch or gun is directed toward the progress
    of welding.
    frequency: the completed number of cycles which the oscillating
    head makes in 1 min or other specified time increment.
    frictional resistance in the butt-fusing machine: forceopposing
    movement due to friction in the mechanism
    of the fusing machine.
    fuel gas: a gas such as acetylene, natural gas, hydrogen,
    propane, stabilized methylacetylene propadiene, and
    other fuels normally used with oxygen in one of the
    oxyfuel processes and for heating.
    fused spray deposit (thermal spraying): a self-fluxing
    thermal spray deposit which is subsequently heated to
    coalescence within itself and with the substrate.
    fusing (plastic fusing): the process of producing a fusion
    joint. Butt, manual butt, electrofusion, and sidewall are the
    fusing processes addressed in this Code.
    fusing gauge pressure: the hydraulic gauge pressure to be
    observed by the fusing operator when butt fusing or sidewall
    fusing polyethylene (PE) piping. This is the sum of the
    theoretical fusing pressure plus the drag pressure.
    fusing operator: person trained and qualified to carry out
    fusing of polyethylene (PE) pipes and/or fittings using a
    butt-fusing or sidewall-fusing procedure or electrofusion
    procedure with applicable equipment.
    fusing procedure specification: a document providing in
    detail the required variables for the fusing process to
    ensure repeatability in the fusing procedure. This
    generic term includes fusing procedure specifications
    qualified by testing (FPS), as well as standard fusing procedure
    specifications (SFPS) or manufacturer qualified electrofusion
    procedure specifications (MEFPS).
    fusion (fusion welding): the melting together of filler metal
    and base metal, or of base metal only, to produce a weld.
    fusion (plastic fusing): the portion of the fusing process
    involving the coalescence of two plastic members by
    the combination of controlled heating and the application
    of pressure approximately normal to the interface
    between them; the joint produced by plastic fusing.
    fusion face: a surface of the base metal that will be melted
    during welding.
    fusion interfacial pressure: the interfacial pressure applied
    during the fusion phase of the fusing process.
    fusion line: a non-standard term for weld interface.
    gas backing: see backing gas.
    globular transfer (arc welding): a type of metal transfer in
    which molten filler metal is transferred across the arc in
    large droplets.
    groove weld: a weld made in a groove formed within a
    single member or in the groove between two members
    to be joined. The standard types of groove weld are as
    follows:

    crack: a fracture-type discontinuity characterized by a
    sharp tip and high ratio of length and width to
    opening displacement.
    creep strength enhanced ferritic alloys (CSEF’s): a family of
    ferritic steels whose creep temperature strength is
    enhanced by the creation of a precise condition of microstructure,
    specifically martensite or bainite, which is stabilized
    during tempering by controlled precipitation of
    temper-resistant carbides, carbo-nitrides, or other
    stable and/or meta-stable phases.
    data acquisition record: a detailed, permanent record of
    variables applicable to the fusing process, such as buttfusion
    pressure, electrofusion voltage, and cycle cooldown
    times, along with the measured heater surface
    temperature, employee information, butt-fusing or electrofusion
    machine information, pipe information, date,
    and time for each joint made.
    defect: a discontinuity or discontinuities that by nature or
    accumulated effect (for example, total crack length)
    render a part or product unable to meet minimum applicable
    acceptance standards or specifications. This term
    designates rejectability. See also discontinuity and flaw.
    direct current electrode negative (DCEN): the arrangement
    of direct current arc welding leads in which the electrode
    is the negative pole and the workpiece is the positive pole
    of the welding arc.
    direct current electrode positive (DCEP): the arrangement
    of direct current arc welding leads in which the electrode
    is the positive pole and the workpiece is the negative pole
    of the welding arc.
    discontinuity: an interruption of the typical structure of a
    material, such as a lack of homogeneity in its mechanical,
    metallurgical, or physical characteristics. A discontinuity
    is not necessarily a defect. See also defect and flaw.
    double-welded joint: a joint that is welded from both sides.
    double-welded lap joint: a lap joint in which the overlapped
    edges of the members to be joined are welded along the
    edges of both members.
    drag pressure: the pressure required to overcome the drag
    resistance and frictional resistance in the butt-fusing
    machine and keep the carriage moving at its slowest
    speed.
    drag resistance: force-opposing movement of the movable
    clamp of the butt-fusing machine due to the weight of the
    pipe.
    dwell: the time during which the energy source pauses at
    any point in each oscillation.
    electrode, arc welding: a component of the welding circuit
    through which current is conducted.
    electrode, bare: a filler metal electrode that has been
    produced as a wire, strip, or bar with no coating or
    covering other than that incidental to its manufacture
    or provided for purposes of preservation, feeding, or electrical
    contact.
    electrode, carbon: a nonfiller material electrode used in arc
    welding and cutting, consisting of a carbon or graphite rod,
    which may be coated with copper or other materials.
    electrode, composite: a generic term of multicomponent
    filler metal electrodes in various physical forms, such
    as stranded wires, tubes, and covered electrodes.
    electrode, covered: a composite filler metal electrode
    consisting of a core of a bare electrode or metal-cored
    electrode to which a covering sufficient to provide a
    slag layer on the weld metal has been applied. The
    covering may contain materials providing such functions
    as shielding from the atmosphere, deoxidation, and arc
    stabilization, and can serve as a source of metallic additions
    to the weld.
    electrode, electroslag welding: a filler metal component of
    the welding circuit through which current is conducted
    between the electrode guiding member and the molten
    slag.
    NOTE: Bare electrodes and composite electrodes as defined
    under arc welding electrode are used for electroslag welding.
    A consumable guide may also be used as part of the electroslag
    welding electrode system.
    electrode, emissive: a filler metal electrode consisting of a
    core of a bare electrode or a composite electrode to which
    a very light coating has been applied to produce a stable
    arc.
    electrode, flux-cored: a composite filler metal electrode
    consisting of a metal tube or other hollow configuration
    containing ingredients to provide such functions as
    shielding atmosphere, deoxidation, arc stabilization,
    and slag formation. Alloying materials may be included
    in the core. External shielding may or may not be used.
    electrode, lightly coated: a filler metal electrode consisting
    of a metal wire with a light coating applied subsequent to
    the drawing operation, primarily for stabilizing the arc.
    electrode, metal: a filler or nonfiller metal electrode used in
    arc welding and cutting that consists of a metal wire or rod
    that has been manufactured by any method and that is
    either bare or covered.
    electrode, metal-cored: a composite filler metal electrode
    consisting of a metal tube or other hollow configuration
    containing alloying ingredients. Minor amounts of ingredients
    providing such functions as arc stabilization and
    fluxing of oxides may be included. External shielding
    gas may or may not be used.
    electrode, resistance welding: the part of a resistance
    welding machine through which the welding current
    and, in most cases, force are applied directly to the workpiece.
    The electrode may be in the form of a rotating wheel,
    rotating roll, bar, cylinder, plate, clamp, chuck, or modification
    thereof.
    ASME BPVC.IX-2025

  • ASME Sec IX 2025

    ASME Sec IX 2025 GENERAL REQUIREMENTS
    ð25Þ QG-100 SCOPE
    (a) This Section contains requirements for the qualification
    of welders, welding operators, brazers, brazing
    operators, plastic fusing operators, and the materialjoining
    processes they use during welding, brazing, and
    fusing operations for the construction of components
    under the rules of the ASME Boiler and Pressure
    Vessel Code, the ASME B31 Codes for Pressure Piping,
    and other Codes, standards, and specifications that reference
    this Section. This Section is divided into four parts.
    (1) Part QG contains general requirements for all
    material-joining processes.
    (2) Part QW contains requirements for welding.
    (3) Part QB contains requirements for brazing.
    (4) Part QF contains requirements for plastic fusing.
    (b) Whenever the referencing Code, standard, or specification
    imposes qualification requirements different
    than those given in this Section, the requirements of
    the referencing Code, standard, or specification shall
    take precedence over the requirements of this Section.
    (c) Some of the more common terms relating to material-
    joining processes are defined in QG-109. Whenever
    the word “pipe” is used, “tube” shall also be applicable.
    (d) New editions to Section IX may be used beginning
    with the date of issuance and become mandatory 6 months
    after the date of issuance.
    (e) Code Cases are permissible and may be used, beginning
    with the date of approval by ASME. Only Code Cases
    that are specifically identified as being applicable to this
    Section may be used. At the time a Code Case is applied,
    only the latest revision may be used. Code Cases that have
    been incorporated into this Section or have been annulled
    shall not be used for new qualifications, unless permitted
    by the referencing Code. Qualifications using the provisions
    of a Code Case remain valid after the Code Case
    is annulled. The Code Case number shall be listed on
    the qualification record(s).
    (f) Throughout this Section, references are made to
    various non-ASME documents. Unless a specific date is
    referenced, the latest edition of the reference document
    in effect at the time of performance or procedure qualification
    is to be used.
    (g) This Section does not fully address tolerances.
    When dimensions, sizes, or other parameters are not
    specified as maximums, minimums, or with tolerances,
    the values of these parameters are considered nominal,
    and allowable tolerances or local variances may be considered
    acceptable when using standard practices based on
    engineering judgment.
    QG-101 PROCEDURE SPECIFICATION
    A procedure specification is a written document
    providing direction to the person applying the material-
    joining process. Details for the preparation and qualification
    of procedure specifications for welding (WPS),
    brazing (BPS), and fusing (FPS) are given in the respective
    Parts addressing those processes. Procedure specifications
    used by an organization (see QG-109.2) having
    responsibility for operational control of materialjoining
    processes shall have been qualified by that organization,
    or shall be a standard procedure specification
    acceptable under the rules of the applicable Part for
    the joining process to be used. Procedure specifications
    shall be available for reference and review at the fabrication
    site.
    Procedure specifications address the conditions
    (including ranges, if any) under which the materialjoining
    process must be performed. These conditions
    are referred to in this Section as “variables.” A procedure
    specification shall address, as a minimum, the specific
    essential and nonessential variables that are applicable
    to the material-joining process to be used in production.
    When the referencing code, standard, or specification
    requires toughness qualification of the material-joining
    procedure, the applicable supplementary essential variables
    shall also be addressed in the procedure specification.
    QG-102 PROCEDURE QUALIFICATION RECORD
    The purpose of qualifying the procedure specification is
    to demonstrate that the joining process proposed for
    construction is capable of producing joints having the
    required mechanical properties for the intended application.
    Qualification of the procedure specification demonstrates
    the mechanical properties of the joint made using a
    joining process, and not the skill of the person using the
    joining process.
    The procedure qualification record (PQR) documents
    what occurred during the production of a procedure qualification
    test coupon and the results of testing that coupon.
    ASME BPVC.IX-2025
    1QG-106.1 Procedure Qualifications. Each organization
    is responsible for conducting the tests required by
    this Section to qualify the procedures that are used in
    the construction of components under the rules of the
    Codes, standards, and specifications that reference this
    Section.
    (a) The personnel who produce test joints for procedure
    qualification shall be under the full supervision and
    control of the qualifying organization during the production
    of these test joints.
    (b) Production of qualification test joints under the
    supervision and control of another organization is not
    permitted, except as permitted in QG-106.4. However,
    it is permitted to subcontract any or all of the work necessary
    for preparing the materials to be joined, the subsequent
    work for preparing test specimens from the
    completed test joint, and the performance of nondestructive
    examination and mechanical tests, provided the organization
    accepts full responsibility for any such work.
    (c) If the effective operational control of procedure
    qualifications for two or more companies of different
    names exists under the same corporate ownership, the
    companies involved shall describe in their quality
    programs the operational control of procedure qualifications.
    In this case, separate procedure qualifications are
    not required, provided all other requirements of this
    Section are met.
    QG-106.2 Performance Qualifications. Each organization
    is responsible for the supervision and control of material
    joining performed by persons for whom they have
    operational responsibility and control. The organization
    shall conduct the tests required by this Section to qualify
    the performance of those persons with each joining
    process they will use for the construction of components
    under the rules of the Codes, standards, and specifications
    that reference this Section. This requirement ensures that
    the qualifying organization has determined that the personnel
    using its procedures are capable of achieving the
    minimum requirements specified for an acceptable joint.
    This responsibility cannot be delegated to another organization.
    (a) The personnel who produce test joints for performance
    qualification shall be tested under the full supervision
    and control of the qualifying organization.
    (b) The performance qualification test shall be
    performed following either a qualified procedure specification
    or a standard procedure specification acceptable
    under the rules of the applicable Part for the joining
    process. The Part addressing any specific joining
    process may exempt a portion of the procedure specification
    from being followed during production of the
    performance qualification test coupon.
    (c) Production of test joints under the supervision and
    control of another organization is not permitted. It is
    permitted to subcontract any or all of the work necessary
    for preparing the materials to be joined in the test joint,
    and the subsequent work for preparing test specimens
    from the completed test joint, and the performance of
    nondestructive examination and mechanical tests,
    provided the organization accepts full responsibility
    for any such work.
    (d) The performance qualification test may be terminated
    at any stage, whenever it becomes apparent to the
    supervisor conducting the tests that the person being
    tested does not have the required skill to produce satisfactory
    results.
    (e) When a procedure qualification test coupon has
    been tested and found acceptable, the person who
    prepared the test coupon is also qualified for the
    joining process used, within the ranges specified for
    performance qualification for the applicable process(es).
    (f) Persons who are successfully qualified shall be
    assigned an identifying number, letter, or symbol by
    the organization, which shall be used to identify their
    work.
    (g) If effective operational control of performance
    qualifications for two or more companies of different
    names exists under the same corporate ownership, the
    companies involved shall describe in their quality
    programs the operational control of performance qualifications.
    In this case, requalification of persons working
    within the companies of such an organization are not
    required, provided all other requirements of this
    Section are met.
    QG-106.3 Simultaneous Performance Qualifications.
    Organizations may participate in an association to collectively
    qualify the performance of one or more persons for
    material-joining processes simultaneously and may share
    performance qualification information with other participating
    organizations within the association. When simultaneous
    performance qualifications are conducted, each
    participating organization shall be represented by an
    employee with designated responsibility for performance
    qualifications.
    (a) The essential variables of the procedure specifications
    to be followed during simultaneous performance
    qualifications shall be compared by the participating organizations,
    and shall be identical, except as otherwise
    provided in the Part addressing the specific joining
    method. The qualified thickness ranges need not be identical
    but shall include the test coupon thickness.
    (b) Alternatively, the participating organizations shall
    agree to follow a single procedure specification that has
    been reviewed and accepted by each participating organization.
    Each participating organization shall have a
    supporting PQR or shall have accepted responsibility
    for using a standard procedure specification having a
    range of variables consistent with those to be followed
    during the performance qualification test, in accordance
    with the applicable Part for the joining method.
    (c) Each participating organization’s representative
    shall

    brazing, block (BB): a brazing process that uses heat from
    heated blocks applied to the joint. This is an obsolete or
    seldom used process.
    brazing, dip (DB): a brazing process in which the heat
    required is furnished by a molten chemical or metal
    bath. When a molten chemical bath is used, the bath
    may act as a flux; when a molten metal bath is used,
    the bath provides the filler metal.
    brazing, furnace (FB): a brazing process in which the workpieces
    are placed in a furnace and heated to the brazing
    temperature.
    brazing, induction (IB): a brazing process that uses heat
    from the resistance of the workpieces to induced electric
    current.
    brazing, machine: brazing with equipment which
    performs the brazing operation under the constant observation
    and control of a brazing operator. The equipment
    may or may not perform the loading and unloading of the
    work.
    brazing, manual: a brazing operation performed and
    controlled completely by hand. See also automatic
    brazing and machine brazing.
    brazing, resistance (RB): a brazing process that uses heat
    from the resistance to electric current flow in a circuit of
    which the workpieces are a part.
    brazing, semiautomatic: brazing with equipment which
    controls only the brazing filler metal feed. The advance
    of the brazing is manually controlled.
    brazing, torch (TB): a brazing process that uses heat from a
    fuel gas flame.
    build-up of base metal (restoration of base metal thickness):
    this is the application of a weld material to a base metal so
    as to restore the design thickness and/or structural integrity.
    This build-up may be with a chemistry different from
    the base metal chemistry which has been qualified via a
    standard butt-welded test coupon. Also, may be called
    base metal repair or buildup.
    butt joint: a joint between two members aligned approximately
    in the same plane.
    butt-fusing cycle: pressure–time diagram for a defined
    fusing temperature, representing the entire fusing operation.
    butt-fusing pressure: the sum of the theoretical butt-fusing
    pressure plus the drag pressure. This is verified by the
    gauge pressure used by the fusing operator on the
    butt-fusing machine to join the pipe ends or by applied
    torque when torque verification is required by the
    fusing procedure specification (FPS).
    butt fusion (BF): fusing accomplished by heating the ends
    of polyethylene pipes above their melting point using a
    contact heater, then removing the heater and applying
    pressure necessary to achieve coalescence of the
    molten polyethylene materials during the cooling
    phase. Some of the more common terms relating to BF
    are defined in ASTM F412.
    buttering: the addition of material, by welding, on one or
    both faces of a joint, prior to the preparation of the joint for
    final welding, for the purpose of providing a suitable transition
    weld deposit for the subsequent completion of the
    joint.
    clad or cladding: weld metal overlay or bonded corrosionresistant
    material added to a metal surface.
    clad brazing sheet: a metal sheet on which one or both
    sides are clad with brazing filler metal.
    coalescence: the growing together or growth into one body
    of the materials being joined.
    complete fusion: fusion which has occurred over the entire
    base material surfaces intended for welding, and between
    all layers and beads.
    consumable insert: filler metal that is placed at the joint
    root before welding, and is intended to be completely
    fused into the root to become part of the weld.
    contact tube: a device which transfers current to a continuous
    electrode.
    control method (FSW): the manner of monitoring and
    controlling the position of the rotating tool with
    respect to the weld joint during the friction stir
    welding process.
    control method, force (FSW): a control method that uses a
    force set point, such as plunge force or travel force, to
    control the tool position. Under the force control
    method, the plunge depth or travel speed can vary,
    within a specified range, during welding.
    control method, position (FSW): a control method that uses
    a set plunge position relative to the plate surface to control
    the tool position. Under the position control method, the
    plunge force can vary, within a specified range, during
    welding.
    control method, travel (FSW): a control method that uses a
    set travel speed to control the tool position. Under the
    travel control method, the travel force can vary, within
    a specified range, during welding.
    control specimen: a section from the base material tested
    to determine its tensile strength for the purpose of
    comparing to the tensile strength of the fused joint.
    cool time at butt-fusing pressure: the minimum time that
    the butt-fusing pressure shall be maintained between the
    pipe faces while the pipe joint cools. This is a function of
    the wall thickness.
    corner joint: a joint between two members located
    approximately at right angles to each other in the form
    of an L.
    coupon: see test coupon.

  • AS (RISSB) 7501:2019

    AS (RISSB) 7501:2019: A Complete Guide to Railway Track and Infrastructure Requirements

    AS (RISSB) 7501:2019 is an important Australian railway standard that provides technical requirements and guidance for railway infrastructure. For railway operators, infrastructure managers, engineers, contractors, and suppliers, understanding the requirements of this standard can help improve safety, reliability, compliance, and asset performance.

    In this guide, we explain what AS (RISSB) 7501:2019 is, why it matters, who should use it, and how organizations can approach compliance and implementation in railway projects.

    What Is AS (RISSB) 7501:2019?

    AS (RISSB) 7501:2019 is an Australian railway standard developed within the Rail Industry Safety and Standards Board (RISSB) framework.

    The standard forms part of Australia’s broader railway standards system, which aims to establish consistent technical and safety requirements across the rail industry. It is intended to support railway organizations in designing, managing, maintaining, and operating railway infrastructure in a controlled and consistent manner.

    For organizations working on Australian railway projects, understanding the scope and application of AS (RISSB) 7501:2019 is particularly important when developing engineering specifications, procurement requirements, inspection procedures, and maintenance programs.

    Why Is AS (RISSB) 7501:2019 Important?

    Railway infrastructure operates in a demanding environment. Track systems and associated infrastructure are exposed to heavy axle loads, repeated dynamic forces, weather conditions, vibration, and long-term wear.

    A structured technical standard helps organizations establish consistent requirements throughout the asset lifecycle.

    Key benefits of applying AS (RISSB) 7501:2019 principles can include:

    • Improved railway safety
    • More consistent engineering practices
    • Better asset reliability
    • Reduced infrastructure-related risks
    • Improved maintenance planning
    • Greater consistency between project stakeholders
    • More effective quality assurance
    • Support for regulatory and contractual compliance

    The standard can therefore play an important role in the development and management of railway infrastructure in Australia.

    Who Should Use AS (RISSB) 7501:2019?

    AS (RISSB) 7501:2019 can be relevant to a wide range of railway industry professionals and organizations.

    Railway Infrastructure Managers

    Infrastructure managers need reliable technical requirements for managing railway assets throughout their operational life. Applying relevant railway standards can help establish consistent inspection, maintenance, and asset-management practices.

    Railway Engineers

    Civil, track, structural, mechanical, and systems engineers may need to consider applicable requirements when designing or modifying railway infrastructure.

    Railway Contractors

    Contractors involved in railway construction, renewal, maintenance, or upgrade projects should understand the applicable standards specified by the project owner or infrastructure manager.

    Railway Equipment and Material Suppliers

    Manufacturers and suppliers may need to demonstrate that their products or services meet specified railway requirements. Understanding the applicable standards can help suppliers prepare appropriate technical documentation and quality-control procedures.

    Railway Operators

    Operators rely on safe and reliable infrastructure to maintain efficient train services. Appropriate standards can support cooperation between infrastructure managers and railway operators.

    Key Areas to Consider When Applying AS (RISSB) 7501:2019

    Successful implementation of a railway standard involves more than simply referencing the standard in a project document. Organizations should consider how its requirements interact with engineering design, procurement, construction, inspection, testing, operation, and maintenance.

    1. Engineering and Design

    Railway infrastructure should be designed according to the applicable technical requirements, project conditions, operational requirements, and risk profile.

    Engineers should identify relevant requirements early in the design process and ensure that specifications, drawings, calculations, and technical documentation are consistent with the selected standards.

    2. Material and Component Selection

    The selection of appropriate materials and components is essential for railway infrastructure performance.

    Organizations should establish clear technical specifications for materials and components and verify that supplied products meet the requirements established by the project.

    3. Construction and Installation

    Even a well-designed railway system can experience performance problems if construction and installation activities are not properly controlled.

    Quality assurance should cover critical construction processes, workmanship, inspection points, testing, and documentation.

    4. Inspection and Testing

    Inspection and testing provide evidence that railway infrastructure has been constructed or maintained according to specified requirements.

    Depending on the project, inspection activities may include dimensional checks, visual inspections, material verification, condition assessments, and other appropriate tests.

    5. Maintenance and Asset Management

    Railway infrastructure is a long-life asset. Maintenance strategies should take account of operational conditions, asset condition, deterioration mechanisms, and safety risks.

    Using consistent technical requirements can help infrastructure managers develop more systematic maintenance and inspection programs.

    AS (RISSB) 7501:2019 and Railway Safety

    Safety is one of the central considerations in railway infrastructure management.

    Railway systems involve significant interaction between trains, track, structures, signaling systems, electrical infrastructure, workers, and passengers. Failure of critical infrastructure can have serious operational and safety consequences.

    For this reason, organizations should not treat AS (RISSB) 7501:2019 as an isolated document. Its requirements should be considered alongside applicable legislation, network rules, engineering standards, risk-management processes, and project-specific specifications.

    A practical railway safety strategy should identify hazards, assess risks, implement appropriate controls, and verify that controls remain effective throughout the asset lifecycle.

    How to Implement AS (RISSB) 7501:2019 in a Railway Project

    Organizations can take a structured approach when applying AS (RISSB) 7501:2019.

    Step 1: Identify Applicable Requirements

    Start by determining whether AS (RISSB) 7501:2019 applies to the specific asset, activity, or project.

    The project team should also identify related Australian Standards, RISSB standards, network-specific requirements, legislation, and contractual obligations.

    Step 2: Develop a Compliance Matrix

    A compliance matrix can help project teams track individual requirements.

    A typical matrix may include:

    RequirementProject ApplicationResponsible PersonEvidenceStatus
    Technical requirementApplicableEngineering TeamDesign documentsOpen
    Material requirementApplicableProcurement TeamSupplier documentsComplete
    Inspection requirementApplicableQA/QC TeamInspection recordsOpen
    Testing requirementApplicableTesting TeamTest reportsOpen

    This approach makes it easier to identify gaps before construction or commissioning.

    Step 3: Integrate Requirements Into Design Documents

    Relevant requirements should be incorporated into engineering specifications, drawings, calculations, procurement documents, inspection plans, and construction procedures.

    Step 4: Control Procurement

    Procurement teams should communicate technical requirements clearly to suppliers and contractors.

    Supplier documentation should be reviewed against the applicable specifications before products are accepted for use.

    Step 5: Verify Construction Quality

    Inspection and testing should be performed at appropriate stages of construction. Non-conforming work should be documented, assessed, and corrected through an established quality-management process.

    Step 6: Maintain Compliance Records

    Organizations should retain appropriate evidence, including inspection reports, test results, certificates, engineering approvals, non-conformance records, and commissioning documentation.

    Good documentation supports both project handover and future asset management.

    Common Challenges When Working With Railway Standards

    Railway standards can be technically complex, particularly when multiple standards and project requirements apply simultaneously.

    Some common challenges include:

    Different Requirements Across Projects

    Australian railway networks may have their own engineering standards, specifications, and operational requirements. A requirement applicable to one network may not automatically apply to another.

    Keeping Standards Up to Date

    Standards can be revised or replaced. Organizations should establish a process for monitoring applicable standards and confirming that project documentation uses the correct edition.

    Interpreting Technical Requirements

    Some requirements may require engineering judgment and careful consideration of the specific application.

    Where interpretation is necessary, organizations should involve appropriately qualified railway engineering professionals.

    Managing Documentation

    Large railway projects generate substantial quantities of technical documentation. Without effective document control, teams may accidentally use outdated drawings, specifications, or procedures.

    AS (RISSB) 7501:2019 Compliance Checklist

    Before using AS (RISSB) 7501:2019 for a railway project, organizations should consider the following checklist:

    • Confirm the applicability and scope of the standard.
    • Identify related railway standards and regulations.
    • Confirm the applicable edition of each standard.
    • Review project-specific engineering requirements.
    • Establish responsibilities for compliance.
    • Develop a requirements or compliance matrix.
    • Include relevant requirements in procurement documents.
    • Verify materials and components.
    • Implement appropriate inspection and testing procedures.
    • Record non-conformances and corrective actions.
    • Maintain technical and quality documentation.
    • Review compliance before commissioning or handover.
    • Ensure maintenance teams have the information required for ongoing asset management.
